Roland VersaUV LEF-12i Benchtop UV Flatbed Printer

$5,100.00
Qty:

Description



LEF-20 advanced features

The LEF-20 fits on a studio, office, or workshop benchtop and is Roland DG’s most advanced compact flatbed option. It offers the following features that make it the most versatile of flatbed printers in its class:

  • Advanced UV-LED curing system to expedite production with two times faster Clear ink and CMYK ink printing
  • An intuitive distance print mode to ensure brilliant print consistency on irregular and curved objects
  • Up to 20 job presets to instantly allow the recall of specific media settings for your most popular applications
  • New height sensor bar made with non-magnetic material for printing on magnetic items such as iPad covers



ECO-UV ink is offered in CMYK, White and Clear, while ECO-UV S in CMYK and White. It instantly dries and produces wide color gamut results with sharp detail and rich color density. ECO-UV requires no degassing and stretches up to 220 percent around curves and irregular surfaces without cracking. ECO-UV inks are extremely durable, giving indoor graphics scratch and chemical resistance, while outdoor graphics last up to six months and upward of two years when a Clear Coat ink layer is applied as a finish. ECO-UV ink is supplied in mess-free 220ml cartridges that are safe after curing. Proper ventilation is required during Eco-UV production and an optional BOFA Air Filtration Unit that was created for use with Roland DG devices is available to virtually eliminate odor and to act as a stand and storage unit for jigs, fixtures and supplies.


Energy efficient and ozone free


The LEF Series of printers simply plug-in to a standard electrical outlet. Using a fraction of the power that other flatbed printers demand, an LEF offers significant savings on electrical costs per year. The LEF Series uses LED lamps for UV-curing that last up to ten times longer than conventional UV lamps and can be instantly switched on or off, giving the user a true on-demand production without the typical warm-up time. In addition, the LEF automatically enters a low-power mode when it is not used for an extended period of time. The LEF’s Roland Eco-label represents environmentally conscious printing. By providing a light source that is entirely ozone free and emitting light in the range known as Near-UV of the UV spectrum, it offers a safe alternative to conventional UV lamps.

Model VersaUV LEF-20VersaUV LEF-12
Printing methodPiezoelectric inkjet / Table feed system
Acceptable mediaWidthMaximum 21.2 in. (538 mm)13.2 in. (335 mm)
DepthMaximum 14.2 in. (360 mm)12.2 in. (310 mm)
ThicknessMaximum 3.94 in. (100 mm)3.94 in. (100 mm)
WeightMaximum 11 lbs (5 kg)11 lbs (5 kg)
Printing areaMaximum 20x13 in. (508x330 mm)12x11 in. (305x280 mm)
Ink cartridgesTypeRoland Eco-UV inks
Capacity6 cartridges - 220 ml (± 5 ml)
Colors6 colors (Cyan, Magenta, Yellow, Black, White and Clear)
ConfigurationCMYK+White+Clear
Ink curing unitSingle UV LED Lamp
Printing resolutionsMaximum 1440x720 dpi
Distance accuracy when printing

(*1)
Error of less than ± 0.3 % of distance traveled, or ± 0.012 in (0.3 mm), whichever is greater
Interface/ConnectivityEthernet (10 BASE-T / 100 BASE-TX, automatic switching)
Power-saving functionAutomatic sleep feature
Power supplyVolatage and frequencyAC 100 to 240 V ± 10%, 50/60 Hz
Required power capacityMaximum 1.8 A
Power consumptionDuring operationApproximately 149 W156 W
Sleep modeApproximately 13 W16.7 W
Acoustic noise levelDuring operation60dB (A) or less
During standby49dB (A) or less
Outer Dimensions47.4 (W) x 37.9 (D) x 21.7 (H) in.

(1,202 (W) x 962 (D) x 549 (H) mm)
39.3 x 34.2 x 21.5 in.

(998 (W) x 867 (D) x 546 (H) mm)
Weight242.5 lbs. (110 kg)187.4 lbs. (85 kg)
EnvironmentPower on (*2)Temperature: 68° to 90°F (20° to 32°C) (72°F [22°C] or more recommended),

Humidity: 35 to 80% (no condensation)
Power offTemperature: 41° to 104°F (5° to 40°C),

Humidity: 20 to 80% (no condensation)
Included itemsPower cord, adhesive sheet, software RIP (Roland VersaWorks™), user documentation

*1 Temperature: 25°C or 77°F, humidity: 50%

*2 Operating environment



Optional RotaPrint Specifications

Max. Print Diameter3.03 in (77 mm)
Min. Print Diameter1.57 in (40 mm)
Max Weight Load11 lbs (5kg)
Printing Mode720 x 720 dpi standard resolution CMYK + W or CMYK
CertificationCE Certified
DimensionsBoxed: 31x22x9 in (810x560 x228 mm) weight approx.: 35lb (16.1kg)
Unboxed: 27x20x7 in (695x510x180 mm) weight approx.: 25lb (11.5kg)
Special FeaturesQuickChange Table Mechanism. No alignment required on LEF bed.
  • Availability: 12 In Stock
  • Model: VersaUV LEF-12i
