Newcon Optik NVS 27M 1x 3rd Generation Compact Night Vision Clip-On

Newcon Optik NVS 27M 1x 3rd Generation Compact Night Vision Clip-On
$5,100.00
Qty:
Add to Cart Buy Now
Print

Newcon Optik NVS 27M Specs

Performance
Magnification1x
Angle of View12°
Exit Pupil Diameter42 mm
Minimum Focus Distance33' / 10 m
IR Illuminator
Infrared IlluminatorOptional
General
Intensifier Tube Generation3
Intensifier Tube TypeAutogated, Gallium Arsenide
Lens System78 mm, f/1.1
Resolution64 lp/mm
Environmental
Water ResistanceWaterproof
Environmental ProtectionAdvertised as Water Resistant
*Test Methodology Not Supplied
Operating Temperature-67 to 149°F / -55 to 65°C
Storage Temperature-76 to 158°F / -60 to 70°C
Physical
Battery1 x CR123A (Approx. 60 Hours)
Dimensions8.6 x 3.5 x 3.4" / 220 x 90 x 87 mm
Weight34.2 oz / 970.0 g


Newcon Optik NVS 27M Overview

The NVS 27M 1x 3rd Generation Compact Night Vision Clip-On from Newcon Optik converts your day riflescope into a night vision device. It features a 3rd generation intensifier tube with a Gallium Arsenide photocathode, manual gain, resolution of 64 lp/mm, and a SNR of 25. The 3rd generation image intensifier tube utilizes an autogated power supply that provides outstanding performance and enables operation in high-light conditions, slows-down degradation, and helps extend life of the device. The optical system is designed to accommodate daytime riflescopes with magnification range of 1-20x and offers a 78mm objective lens with f/1.15 F-stop. The optical system also offers a 12° angular field of view and a 33' minimum focus distance. The unit is powered by the included lithium-ion CR-123A battery. The aluminum housing is lightweight, durable, waterproof submersible to 33', and resistant to extreme temperatures.
Intensifier Tube and Illuminator
  • 3rd generation
  • Autogated supply
  • Manual gain control
  • Resolution of 64 lp/mm, and an SNR of 25
  • ABC-Automatic Brightness Control
Optical Performance
  • Magnification: 1x
  • Accommodates scopes with 1-20x magnification
  • Lens system: 78mm, f/1.15
  • Field of view: 12°
  • Close focus: 33'
  • Exit pupil 42mm
Construction Details
  • Compatible with Picatinny rails
  • Withstands extreme temperatures
  • Flip-out lens covers
  • Filled with nitrogen
  • Waterproof, submersible to 33'
